Twin Wall Internal Flue System – Single Storey with Offset – Stainless Steel – 5 Inch

Description This internal flue system is designed for single-storey installations where the flue requires an offset to avoid ceiling joists or other internal obstructions. It provides a safe, insulated route for flue gases to pass through the property and exit through the roof, using premium TWPro Components for long-lasting performance and a professional finish.As every property is different, additional parts may be required depending on ceiling height, roof pitch, or stove position. System design and installation must be carried out by a competent person. For advice or guidance, please contact us on 01253 372 000 or email [email protected]. Approvals TWPro is HETAS Approved and CE marked. Designation Number: EN1856-1 T600 N1 W V2 L50040 G50. EN1856-1 T200 P1 W V2 L50040 O20. Installation TWPro Insulated Chimney Parts are secured together using a Locking Band (supplied). Maintain a distance of 50mm from the outside of the flue to any combustible material (wood, plasterboard). Please Note You are purchasing a FULL Twin Wall System Kit. This set of items can be returned in its entirety, but individual parts/items from the set CANNOT be returned if not required. Set Contents: Item Type Quantity TWPro Silver – Rain Cap – 125mm 1 TWPro Silver – Storm Collar – 125mm 1 Lead Free Flashing 20 to 45°, Stainless Steel Cone, Black Base – (125mm &150mm ID) 1 TWPro Silver – Roof Support – 125mm 1 TWPro Silver – Pipe 1000mm – 125mm 3 TWPro Silver – Adjustable Pipe 350mm to 500mm – 125mm 1 TWPro Silver – 45° Bend – 125mm 2 TWPro Silver – Wall Support 130mm to 210mm – 125mm 1 TWPro Silver – Ventilated Firestop Support Kit (WHITE) – 125mm 1 Loft Mesh Kit for Flue Enclosures (125mm) 1 TWPro Silver – Firestop Cover Plate (WHITE) 1 TWPro Silver – Flat Adaptor to SW 5 to 5 – 125mm 1
